Description
| Feature Category | Specification Details |
| Panel & Resolution | |
| LCD Size | 0.59″ LCD |
| Aspect Ratio | 16:10 |
| Native Resolution | WUXGA ($1280 \text{ dots} \times 800 \text{ Lines}$) |
| Maximum Resolution | Up to 1080p |
| Pixel Numbers | $1,024,000$ |
| Light Output (Brightness) | 4000 lm (Lumens) |
| Contrast Ratio | 16,000:1 with Iris |
| Color Reproduction | 10-bit signal processing, 1.07 billion colors |
| Light Source (Lamp) | |
| Lamp Type | Signify Infinity: 240W |
| Lamp Power (Boost/Normal/ECO1/ECO2) | 240W / 225W / 180W / 150W |
| Lamp Life (Boost/Normal/ECO1/ECO2) | 8,000H / 10,000H / 12,000H / 20,000H |
| Filter Life | 10,000H |
| Lens & Projection | |
| Zoom & Focus | Manual |
| Zoom Ratio | 1.2x |
| Throw Ratio | 1.5 – 1.8 |
| F-number/Focal Length | F: 1.6 – 1.76 / f = 19.158 – 23.018mm |
| Image Size (Guaranteed Range) | 30″ to 300″ ($40″ \text{ to } 200″$) |
| Keystone Correction | Horizontal, Vertical |
| Connectivity (Input) | |
| HDMI® (Type A 19pin) | 2 |
| Mini D-Sub 15pin | 1 (R/G/B, H/V Sync, Composite Sync, Y, Cb/Cr specifications provided) |
| RCA (Video) | 1 (Composite Video, Compatible signals: NTSC/PAL/SECAM variants) |
| USB Type A | 1 (for USB memory or Wireless LAN, 1.5 External output) |
| USB Type B | 1 (for Service) |
| LAN (Wired) | 1 (RJ-45, 100Base-TX/10Base-T) |
| Wireless LAN | Optional via USB Type A (W-LAN) |
| Audio | |
| Built-In Speaker | 16W monaural |
| General & Warranty | |
| Power Requirement | 100 to 240 VAC, 50/60 Hz |
| Included in Box | VGA Cable, Remote Control, Power Cable (NO BAG) |
| Warranty (Spare Part) | 3 Years |
| Warranty (Lamp) | 500 hours or 6 months, whichever comes first |
